DataTable
| # | ITEM | DESCRIPTION |
|---|---|---|
| 1 | Display | 6 Digits Red 7 Segment LED |
| 2 | Power Supply | 200-230 Vac, 50 or 60 Hz, 1 A / 15 V 500 mA |
| 3 | Signal | Analog 1-3 mV/V |
| 4 | Excitation Voltage | 5 +/- 0,1 Vdc |
| 5 | Internal Resolution | Up to 1/150,000 |
| 6 | Display increment | 10,000 Levels |
| 7 | Loadcell | Up to 4 Loaccell |
| 8 | Calibration Method | Software, Storage in EEPROM |
| 9 | Decimal point | 0 - 4 Digits |
| 10 | Increment Step | 1, 2, 5, 10, 20 |
| 11 | Keyboard | 6 Keys |
| 12 | Communication | 2 x RS-232C |
| 13 | Casing | Stainless Steel + Aluminum |
